BoosterTech Campus Overview
SSD Solutions
Auto SSD Asssembly and Testing Lin
|
Project Brief |
Auto SSD Assembly and Resting Line |
|
Product Brief |
SSD, 6 SKUs |
|
Delivery Location |
VN |
|
Key Features |
● Operation Mode – fully automated SSD assembly process, support 6 SKUs ● Line Capacity – UPH 100 ● Material Feeding – ütrays for housing and heatsinks ümagazine for PCBAs ● Material Transfer – Dual layer circular conveyor, common carrier ● Material Handling – Dual gripper to same pick & place time ● Robot – ü6-axis robots üScara robot üGantry systems ● Gripper Quick Changeover – quick lock/exchange mechanism for gripper exchange ● Vision Embedded – robot guiding ● Modular design – Common frame, common robot stands, segmented conveyors, easy for repurpose ● Serviceability – easy access to system control module and functional modules inside |
|
Process Coverage |
● Material loading – Baffle, PCBA, Heatsink etc… ● Parts lock and pressing ● Screwing ● Labeling Light pipe checking |
Auto SSD PCBA ICT Testing Line
|
Project Brief |
Auto SSD PCBA ICT Testing Line |
|
Product Brief |
SSD PCBA, 6 SKUs |
|
Delivery Location |
VN |
|
Key Features
|
● Operation Mode – fully automated ICT test for SSD PCBA ● One robot arm handles 3 ICT Testers ● Line Capacity – UPH 100 ● Material Feeding – tray feeders for PCBA ● Material Transfer – Robot pick and place ● Material Handling – Triple gripper to same pick & place time ● 7-axis robot – 6-axis robot on slider üHoming sensor for 7th axis ürepeated positioning accuracy ±0.1mm üMoving speed 0~150mm/s adjustable ● Gripper Quick Changeover – quick lock/exchange mechanism for gripper exchange ● Vision Embedded – robot guiding ● Modular design – Common frame, common robot stands, segmented conveyors, easy for repurpose ● Serviceability – easy access to system control module and functional modules inside |
|
Process Coverage |
● Material loading – tray feeders for PCBA ● ICT Testing, Keysight 3070 ● Robot moving on rails |
Auto SSD Burn-ln Line
|
Project Brief |
Auto SSD Burn-In Line |
|
Product Brief |
SSD, 6 SKUs |
|
Delivery Location |
VN |
|
Key Features
|
● Operation Mode – fully automated burn-in test ü14 burn-in racks handled by 1 robot arm ü8 layers for each burn-in rack ü20 cavities for each layer ● Burn-in Capacity – 2240 cavities ● Burn-in Time – 3~35 hours ● Material Feeding – tray feeders for load and unload ● Material Transfer – üRobot gripper pick and place üDual layer circular conveyor üCommon pallet with RFID tracking ● 7-axis robot – 6-axis robot on slider üHoming sensor for 7th axis ürepeated positioning accuracy ±0.1mm üMoving speed 0~150mm/s adjustable ● Gripper Quick Changeover – quick lock/exchange mechanism for gripper exchange ● Vision Embedded – robot guiding ● Modular design – Common frame, common robot stands, segmented conveyors, easy for repurpose ● Serviceability – easy access to system control module and functional modules inside |
|
Process Coverage |
● Material loading – tray feeders for PCBA ● Burn-in test ● Robot moving on rails |
